Denisova Track Settings

Denisova Sequence Reads   (All Denisova Assembly and Analysis tracks)

Display mode:

Display read names
Attempt to join paired end reads by name
Minimum alignment quality:

Color track by bases: Help on base coloring

Alignment Gap/Insertion Display Options Help on display options
Draw double horizontal lines when both genome and query have an insertion
Draw a vertical purple line for an insertion at the beginning or end of the
query, orange for insertion in the middle of the query
Draw a vertical green line where query has a polyA tail insertion

Additional coloring modes:
Color by strand (blue for +, red for -)
Use gray for
No additional coloring

Display data as a density graph:

BAM configuration help

View table schema
Data last updated at UCSC: 2010-11-16

Denisova cave
Denisova cave entrance in the Altai Mountains of Siberia, Russia where the bones were found from which DNA was sequenced (Copyright (C) 2010, Johannes Krause)

Description

The Denisova track shows Denisova sequence reads mapped to the human genome. The Denisova sequence was generated from a phalanx bone excavated from Denisova Cave in the Altai Mountains in southern Siberia.

Methods

Denisova sequence libraries were prepared by treating DNA extracted from a single phalanx bone with two enzymes: uracil-DNA-glycosylase, which removes uracil residues from DNA to leave abasic sites, and endonuclease VIII, which cuts DNA at the 59 and 39 sides of abasic sites. Subsequent incubation with T4 polynucleotide kinase and T4 DNA polymerase was used to generate phosphorylated blunt ends that are amenable to adaptor ligation. Because the great majority of uracil residues occur close to the ends of ancient DNA molecules, this procedure leads to only a moderate reduction in average length of the molecules in the library, but a several-fold reduction in uracil-derived nucleotide misincorporation. Reads were aligned to human sequence Mar. 2006 (NCBI36/hg18) using the Burrows-Wheeler Aligner.

Download the Denisova track data sets from the Genome Browser downloads server.

References

Briggs A.W., Stenzel U., Meyer M., Krause J., Kircher M., Pääbo S. Removal of deaminated cytosines and detection of in vivo methylation in ancient DNA. Nucleic Acids Res. 2009 Dec 22:38(6) e87.

Reich D., Green R.E., Kircher M., Krause J., Patterson N., Durand E.Y., Viola B., Briggs A.W., Stenzel U., Johnson P.L.F. et al. Genetic history of an archaic hominin group from Denisova Cave in Siberia. Nature. 2010 Dec 23;468:1053-1060.

Credits

This track was produced at UCSC using data generated by the Max Planck Institute for Evolutionary Anthropology.
